Brand Name : OEM / ODM
Model Number : TRD10
Certification : CE FCC
Place of Origin : Sichuang,China
MOQ : 1pc
Price : Negotiable
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
Supply Ability : 30000 Pieces per Month
Delivery Time : 7-30 days
Packaging Details : customization
Product name : Digital night vision rifle scope
Magnification : 1X
Display screen : 1.6inch 640X480HD TFT
sensor : 1/3”CMOS Sensor 1.2M pixel 1288X968
Objective lens : 20mm
Field of view : 7.4°×5.5°
Memory Card : 8GB
MOA : 1/4 MOA
★➧Digital night vision monocular with 1x magnification, 20mm objective lens,1.6-inch 640X480HD TFT LCD,HD 1920x1080P/30fps video recording
★➧Multi-function design,with Camera & Camcorder function:can be used as telescope,camera and video recorder.
★➧Day/Night mode – full color viewing for day use; black and white or classic green and other four colors for night vision mode
★➧High-definition sensor – 1/3”CMOS Sensor 1.2M pixel 1288X968




Specifications:
| TRD10 Digital night vision rifle scope | |
| Hardware parameters | |
| model | TRD10 |
| sensor | 1/3”CMOS Sensor 1.2M pixel 1288X968 |
| Display screen | 1.6inch 640X480HD TFT |
| Optical parameters | |
| Objective lens aperture | 20mm,F1.1 |
| Magnification | 1X |
| Field of view | 7.4°×5.5° |
| Video parameters | |
| Standard video resolution | 1920x1080P/30fps , |
| 1280X720P/30fps, | |
| 848x480P/30fps | |
| Video format | MP4 |
| Segmented video time | 5 minutes/10 minutes/15 minutes/30 minutes |
| Loop video | support |
| Slideshow | support |
| Memory Card | 8GB |
| Operation function | |
| boot time | < 3s |
| Electronic zoom | support digital continuous zoom, up to 8X |
| Video recording | support |
| Screen brightness adjustment | support |
| Image color | support four image colors |
| Reticle selection | support, support 4 kinds of reticle |
| Center calibration of reticle | support |
| time setting | support |
| language | Six languages including Chinese and English |
| Electronic parameters | |
| Battery | 16340/18350 Rechargeable Lithium Battery(3.7V) |
| Power Adapter | 5V/2A |
| Charging time | < 180 minutes |
| Charging status indicator | support |
| Battery life | ≥3hour |
| Battery indicator | support |
| Battery reminder | support |
| Shutdown timer | support |
| Data interface | Mini USB2.0 (charging/PC data connection) |
| Adjustment range | |
| MOA | 1/4 MOA |
| Windage movement range | 30 MOA |
| Elevation movement range | 40 MOA |
| Environmental adaptability | |
| Operating temperature | -40℃~55℃ |
| Storage temperature | -55℃~70℃ |
| Impact resistance | >=600G |
| waterproof level | IP67 |
| other | |
| weight | ≤300g |
| Dimensions | 97×57×59mm |
|
|
Digital Night Vision Rifle Scope With 1.6 Inch TFT LCD High Power Hunting Images |
